BM 14S

BM14S

With a substantial 300 watts of power coming from the 12" woofer and an impressive low frequency limit of 18 Hz, this subwoofer is the perfect match for the BM and M series monitors.



BM14S

Choose finish

Introduction

BM14S

With a substantial 300 watts of power coming from the 12" woofer and an impressive low frequency limit of 18 Hz, this subwoofer is the perfect match for the BM and M series monitors.



With an auto On/Off function, energy usage shuts off after minutes of no input signal, thereby saving energy when the subwoofer is idle. As soon as an input is detected, the auto sensing circuit enables the subwoofer to come back to life.

A satellite filter feature is provided by the BM14S, enabling adjustment of low-pass corner frequencies from 50 to 150Hz of the monitor source signal. The subwoofer will thus take care of the lower and power consuming frequencies, and thereby adding to the performance and clarity of the monitors in the system. This is due to the high-pass filtering feature that the BM14S comes with. If the need arises to daisy-chain more subwoofers to the same system, the low level LFE output gives you exactly that choice.

Technical specifications

Specification sheet for BM Series part 2
System: Active Subwoofer
Frequency Response (+/- 3 dB): 18 Hz - 250 Hz Sub input, 18 Hz - 250 Hz LFE input
Low Frequency Limit: 18 Hz
High Frequency Limit: 50 Hz - 250 Hz Sub input, 150 Hz LFE input
Amplifier Power: 300 W @ 4 Ohms
Crossover Frequencies HP Sat: Flat / 60 Hz / 80 Hz
Low Pass filter: 50 – 150 Hz
Crossover Slope: 2nd order Butterworth
Crossover Bypass: Yes (Flat)
Phase adjustment: 0° / 180°
Inputs: Balanced/XLR
Input Sensitivity for Full Output: 75 mV – 5 V
Maximum Input: 10 Vrms
Specification sheet for BM Series part 1
Input Impedance: 10kohms
Output: Balanced / XLR
Master / Slave Link: Yes
Drive Unit: 12" (30 cm), long throw
Magnetic Shielding: Yes
Internal Cabinet Volume: 31 litres
Bass Principle: Closed
Power Consumption: Max. 325 W
Power Consumption Standby: < 3 W
Mains Voltage: 100-120 V @ 50 - 60Hz
Weight (net): 21 kg
Dimensions (W x H x D): 350 x 368 x 420 mm / 13.8" x 14.5" x 16.5"
