DBM 50

DBM50

From the handcrafted Dynaudio drivers to its beautiful exterior, DBM50 is specifically engineered to perfectly reproduce your desktop mix and truly represents a revolutionary new angle in desktop mixing.



DBM50

Choose finish

Introduction

DBM50

From the handcrafted Dynaudio drivers to its beautiful exterior, DBM50 is specifically engineered to perfectly reproduce your desktop mix and truly represents a revolutionary new angle in desktop mixing.

From the innovative wave guide around the tweeter to the optional addition of the level controller that never compromises the allimportant level interrelationship between speakers, DBM50 is the perfect partner in situations where the only thing that counts is perfection.

DBM50 comes with the option of adding a sleek controller that puts you squarely at the helm of volume control in any situation.

Set and control levels with precision and ease, completely independent of your computer or workstation. The DBM50 controller provides perfect tracking, which guarantees spot-on stereo imaging with unprecedented precision.

Technical specifications

Specification sheet for BM Series part 2
System: Two-way Active Nearfield Monitor
Frequency Response (+/- 3 dB): 46 Hz - 21kHz
Max SPL 1m, pair (IEC Short Term): 117 dB peak
Max SPL 2m, 5.1 (IEC Short Term): N/A
Input level for 85 dB SPL @1m (+4/-10): 80mV @ 0dB setting
Input level for max peak SPL (+4/-10): -10dB: 4.8Vrms, 0dB: 1.5Vrms, +4dB: 1Vrms
Power consumption: Idle: 5.8 W / Max: 94 W
Amplifier power: Tweeter: 50 W / Woofer: 50 W
Resonance Frequency: 39 Hz
Internal Cabinet Volume: 13.9 liters
Bass Principle: Bass Reflex
Specification sheet for BM Series part 1
Crossover Frequencies: 1500 Hz
Crossover Slope: 6 dB/oct
Tweeter: D-281 - 28 mm soft dome, rear chamber, magnetic fluid, 4mm aluminium front, Pure alu wire voice coil
Woofer: 180 mm/7.1", One-piece thermo formed MSP cone, 75mm/3" pure aluminum wire on kapton former
Weight: 7.2 kg / 15,9 lbs
Dimensions (W x H x D): 230 x 348 x 335 mm / 9.1" x 13.7" x 13.2"
Highpass filters: 60Hz, 80Hz, Off
High Pass' Switch: Flat: 25Hz, 2nd order / 60Hz: 60Hz, 2nd order / 80Hz: 80Hz, 2nd order
LF' Switch: +2: +2 dB low shelf 150Hz / 0: Flat / -2: -2 dB low shelf 150Hz
MF' Switch: 0: Flat / -2: -2 dB notch 450Hz Q0,7 / -4: -4 dB notch 450Hz Q0,7
HF' Switch: +1: +1 dB high shelf 1,5kHz / 0: Flat / -1: -1 dB high shelf 1,5kHz
