LYD 8
Astonishing accuracy across the board
Precision, power… and properly honest reproduction. With a pair of LYD 8s taking charge of your music, you can be assured a pitch-perfect performance
Your order
ClosePrecision, power… and properly honest reproduction. With a pair of LYD 8s taking charge of your music, you can be assured a pitch-perfect performance
Nearfield Monitor with 8" Woofer
Bi-amped speaker design with 50W HF/80W LF and state-of-the-art Class-D amplification
Bass extension to extend or curtail the low end frequency response
Two different tunings: one for free standing and one designed for speakers within 50 cm of wall
Sound balance to influence the overall response of the speaker
Made in Denmark
Soundcards and great monitors revolutionized my productions.
Max SPL (1m, pair): | 112dB |
---|---|
Principle: | Bass reflex, rear port |
Crossover Frequencies: | 3.9kHz |
Tweeter: | 1in soft dome |
Mid: | N/A |
Woofer: | 8in |
Dimensions (W x H x D): | 234 x 369 x 328mm |
Weight: | 10.2kg |
Sensitivity (85dB @ 1m, free field): | |
+6dB: | 50mV |
0dB: | 100mV |
-6dB: | 200mV |
Amplifier: | |
---|---|
Power (Tweeter/Woofer): | HF 50W/LF 80W |
Type: | Class D |
Power consumption standby: | <0.5 W |
Power consumption max.: | 100 W |
Input voltage: | 90 - 264 V AC, 50 - 60 Hz |
XLR balanced | |
Inputs: | RCA unbalanced |
Outputs: | N/A |
Cut-off frequencies -6dB limits: | |
Bass extension +10Hz: | 65Hz - 21kHz |
Bass extension 0Hz: | 55Hz - 21kHz |
Bass extension -10Hz: | 45Hz - 21kHz |
Free field frequency response: | 55Hz - 19kHz |
